DUAL 80 RGBW/FC (High Power)

Categories: , , , , .

Description

Elegant and powerful, IP67, the DUAL 80 RGBW/FC is a twin headed LED Lighting fixture with a very wide light output. Using 80 high brightness LEDs RGBW/FC the fixture combines an innovative optic system with large diameter lenses.
The DUAL 80 RGBW /FC has two independent heads, the LEDs are driven and can be operated separately. The two heads can also be adjusted and positioned individually .
Suitable for permanent architectural installations and for temporarily events.

• Standard fixture colour finishing is black. Optional grey and white (art. FX-COLOUR).

Additional information

Source

– n. 80 RGBW (16W) LEDs
– 560W total light power
– Total lm: R 6000, G 12000, B 1850, W 13500
Optic

– 25º (45mm lenses)
– On request: wide and narrow (45 mm lenses)
Available as accessory:

– 65° plan-filter (kit 2 pcs.)
– Barn-door with extensions (kit 4 pcs.)
– Anti-glare (kit 2 pcs.)
Tilt

– Manual 240° (2 adjustable heads +9° each)
Control

– Standard interface: RS-485, optocoupled input
– Protocol: USITT DMX512
Connections

– Signal: 4pin IP 67 Amphenol connector (male-female)
– Main Power: 3x1mm cable 1,5mt.
Available as accessories:

– Wireless DMX receiver
Setup and configuration

– Control panel with touch technology
– Led display with flip function
– Dedicated DMX channel for white balance
– DMX or Auto mode with Master-Slave function
– Intelligent temperature control
– Flicker-free function
– Smooth dimming function
– Halogen simulation
– CYM simulation
Rating protection

– IP 67
DMX Channels

– 13CH mode
– 8CH mode
– 4CH mode
Power Supply

– Voltage range: 88-264VAC, 124-370VDC
– Frequency range: 47-63Hz
– Active Power factor: PF>0.95/230VAC, PF>0.98/115VAC
– Current: 2.1A@230VAC; Fuse T10A
– Power: 500W (on white balance)
Physical

– WxDxH: 657x182x641 mm
– Weight: 32 Kg.
